150x172x51 (24 V)
Code: PD157B-24
External Dimension: 150X172X51mm
Bearing System: Ball bearing
Rated Voltage: 24VDC
Starting Voltage: 9VDC under 25ºC
Operating Voltage: 21.6-26.4VDC under 25ºC
Rated Speed: 2800RPM(±10%)
Rated current: 0.45A(±10%)
Rated Input power: 11W(±10%)
Max Airflow: 158.8CFM(270m3/h)
Max static pressure: 30.7 mm/H20
Life expectancy: 50000hrs under 25ºC
Operating Temperature: -10 ºC ~ +70 ºC
Storage temperature: -20 ºC ~ +70 ºC
Noise Level: 62dBA
Rotation direction Clockwise(from label side)
Frame Aluminum
Impeller PBT
Lead wire Red(+) and Black(-)
