150x172x51 (12 V)
Code: PD157B-12
External Dimension: 150X172X51mm
Bearing System: Ball bearing
Rated Voltage: 12VDC
Starting Voltage: 6VDC under 25ºC
Operating Voltage: 10.8-13.2VDC under 25ºC
Rated Speed: 2800RPM(±10%)
Rated current: 1.0A(±10%)
Rated Input power: 12W(±10%)
Max Airflow: 158.8CFM(270m3/h)
Max static pressure: 30.7 mm/H20
Life expectancy: 50000hrs under 25ºC
Operating Temperature: -10 ºC ~ +70 ºC
Storage temperature: -20 ºC ~ +70 ºC
Noise Level: 62dBA
Rotation direction Clockwise(from label side)
Frame Aluminum
Impeller PBT
Lead wire Red(+) and Black(-)
